On global construction job sites, most mobile concrete pumping devices face site transfer limits, frequent pipe clogging, and high daily maintenance costs. Builders look for integrated pumping equipment with easy operation and site adaptability. The concrete line pump truck solves common concrete pouring pain points for small-to-medium construction projects worldwide.
What Is A Concrete Line Pump Truck
A concrete line pump truck is an integrated truck-mounted pumping machinery combined with a pumping system and driving chassis. Different from trailer concrete pumps needing external traction, it drives directly to working zones and starts operation quickly. It owns flexible site transfer capacity, similar to that of a crawler concrete pump, ideal for frequent multi-site construction work.
Concrete Pump Truck Product Specifications
| Item | Parameter / Sub-item | Specification / Value | Unit / Remarks |
| Driving System | Fuel Type | Diesel | |
| Displacement / Power | 6.7 / 156 | L / kW | |
| Displacement Standard | Euro III | ||
| Tire Model | 8.25R20 | ||
| Axle Base | 5 | m | |
| Quantity Of Axles | 2 | ||
| Max. Driving Speed | 90 | km/h | |
| Front Wheel Base | 1900 | mm | |
| Back Wheel Base | 1800 | mm | |
| Min. Turning Radius | 9 | m | |
| Pumping System | Diesel Engine Power | 186 | kW |
| Driving Mode | Hydraulic Driving | ||
| Oil Cylinder Inner Diameter × Stroke | Ф180×Ф125×1800 | mm | |
| Concrete Cylinder Inner Diameter × Stroke | Ф230×1800 | mm | |
| Oil Pressure Of System | 32 | MPa | |
| Switch Of H-Pressure And L-Pressure | Equipped | ||
| Fuel Tank Capacity | 290 | L | |
| Oil Tank Capacity | 600 | L | |
| Cooling Mode Of Hydraulic System | Fan Cooling | ||
| Max. Theoretical Capacity | H-Pressure: 55 | m³/h | |
| L-Pressure: 100 | |||
| Pumping Distance (H-Pressure) | Max. Horizontal: 880 | Using 125A Pipe (m) | |
| Max. Vertical: 220 | |||
| Hopper Capacity | 0.6 | m³ | |
| Feeding Height | ≤1500 | mm | |
| Concrete Slump | 14~23 | cm | |
| Max. Aggregate Diameter | Crushed Stone: 40 | mm | |
| Pebble: 50 | |||
| Valve | S Valve | ||
| Water Pump For Cleaning | Equipped | ||
| Concrete Pipe Cleaning Mode | Water Cleaning | ||
| Water Tank Capacity | 400 | L | |
| Lubrication Mode | Automatic | ||
| Overall Dimension | Length × Width × Height | 9195 × 2458 × 2623 | mm |
| Full-Load Total Weight | 13500 | kg |
Advantages of Boom Pump Truck for Sale
- Integrated truck chassis supports free inter-site transfer without towing tools
- S-type valve structure reduces concrete blockage to cut onsite cleaning time
- Constant hydraulic pressure ensures a steady concrete discharging effect
- Simple control panel lowers operation difficulty for onsite workers
- Lower daily running cost compared with the standard cement boom truck
Material Used For Concrete Line Pump Truck Core Parts
- Delivery pipeline: High chromium alloy steel, anti-abrasion for mixed aggregate concrete
- Hydraulic cylinder: Forged carbon steel, anti-fatigue under long-hour vibration
- Outer body paint: Weatherproof anti-rust coating, adapted to coastal and highland climates
- Built-in seals: Imported nitrile rubber, to avoid hydraulic oil leakage
Application of Concrete Line Pump Truck
This pumping machine covers mainstream global construction scenarios:
- Residential house foundation pouring
- Indoor floor and building renovation concrete delivery
- Municipal road and small bridge base construction
- Industrial workshop ground hardening work
- Narrow-space suburban construction projects
On-site Production Upgrade Brought
Construction teams gain an obvious on-site efficiency change after using this device. Traditional scattered pumping equipment needs 5-7 staff to finish pipeline layout and feeding work. A concrete line pump truck only needs 2 onsite operators to complete full pouring work. It cuts repeated pipeline disassembly work, shortens the project cycle, and reduces manual labor investment effectively.
Factors That Affect Line Pump Truck Purchase Price
- Custom pumping pressure and chassis configuration options
- Auxiliary pipeline and wearable parts supporting package
- International sea freight and destination port clearance cost
- Local mechanical registration fee for road legal use
- Extended onsite commissioning and operator training service
Real Overseas Buyer Case
Mr. O’Connor contacted the YG official site, searching for a stable boom pump truck for town residential foundation projects. His old pump stopped frequently, delaying 3 scheduled building projects.
Purchase: YG technical team confirmed standard cement boom truck model matching local road rules, signed a formal export contract.
Delivery: Finished container loading, EU customs clearance, and site delivery within 27 working days.
38-day Onsite Feedback:
The concrete line pump truck runs stably on uneven suburban ground. Weekly pipe blockage times drop from 8 times to 1 time. Daily valid working hours rise from 6h to 9.5h. The team cuts 3 temporary workers, saving 2280 EUR monthly labor cost. The client confirms easy daily maintenance and smooth, narrow-road passing performance.
FAQs
Q1: Can this concrete line pump truck work with mixed pebble concrete?
A1: It supports 50mm max pebble aggregate, fits most conventional construction concrete.
Q2: Can workers adjust the pumping speed onsite freely?
A2: Operators adjust hydraulic grade via the electric control cabinet without professional debugging.
Q3: Does YG provide overseas spare parts supply?
A3: YG builds an overseas spare parts warehouse in Europe for fast wearable part delivery.
Q4: Can we customize the chassis brand for local road compliance?
A4: Full chassis brand and size customization is available for global market demands.
Why Choose YG Machinery For Concrete Line Pump Truck
YG Machinery owns 24 years of professional construction machinery manufacturing and export experience. All construction pumps gain official CE certification for global cross-border sales. We provide one-to-one pre-sale site consulting, personalized equipment customization, and full-cycle cross-border after-sales service for all global buyers. If you need a durable, site-adaptive concrete line pump truck, choose YG Machinery. We also supply matched construction machines, including concrete mixing pumps, self-loading mixer trucks, crawler concrete pumps, and boom pump trucks for sale for one-stop equipment purchase.
